  • Dr. Brian Abelson DC

Defrosting Your Frozen Shoulder

Updated: Nov 2, 2022


Frozen Shoulder, also known as Adhesive Capsulitis (AC), is a condition that is characterized by severe pain (especially at night), progressive shoulder stiffness, and loss of shoulder motion.

The signs and symptoms of Frozen Shoulder usually begin gradually and worsen over time. The mystery of Frozen Shoulder lies in the fact that researchers don’t know (and often don’t agree) what causes this condition.

We know that Frozen Shoulder occurs in two to five percent of the general population and is more commonly seen in the diabetic population (occurrence rate of 10-20%). We also know that Frozen Shoulder is more prevalent in women than men and that individuals 40 to 65 years of age are more likely to develop the condition. (10)

Frozen Shoulder is often considered a self-limiting condition, typically lasting from six months to several years. Fortunately, it is common for patients suffering from Frozen Shoulder to find relief in a much shorter time with the right strategy. (6)



WHY ME? CAUSES OF FROZEN SHOULDER

One of the most frustrating aspects of Frozen Shoulder is that patients never really know why they get this condition. Although researchers often disagree about the root cause of Frozen Shoulder, they have concluded that it should be divided into two categories “Primary” and “Secondary” Frozen Shoulder.

  • Frozen shoulder is to be considered Primary if it is of unknown origin (idiopathic),

  • It is considered secondary if it results from a suspected cause or surgical incident. (11)

Possible secondary risk factors that could be related to a Frozen shoulder are:

  • Smoking

  • Extended periods of immobilization.

  • Trauma, injury, or previous surgery to the shoulder.

  • Diabetes, lung disease, heart disease, hyperthyroidism, and Parkinson’s disease.

Note: Smoking increases rotator cuff pathologies and, in general, increases the risk of shoulder dysfunctions. (12)



SHOULDER JOINT ANATOMY AND FROZEN SHOULDER

Your shoulder joint (glenohumeral joint) is a ball and socket joint in which the end of your upper arm (humerus) forms the ball and unites with the socket (glenoid fossa) of the shoulder blade (scapula). In addition to the basic ball-and-socket joint, numerous other structures make up and support this complex structure.

The shoulder joint is surrounded by a ligamentous capsule full of synovial fluid that lubricates the joint and allows for easy movement. Synovial fluid is a viscous, lubricating fluid that is secreted by the membrane lining the joints and tendon sheaths. The Articular capsule, with numerous folds, is designed to allow optimal movement.

The glenohumeral capsule, by itself, is not very strong. However, it is surrounded by the rotator cuff muscles, which act as active ligaments and provide stability for the various structures of the shoulder. The fascia that runs through these muscles also plays a critical role in stabilizing the shoulder joint.

For example, during glenohumeral joint motion, the subscapularis muscle (one of the rotator cuff muscles) coils around the coracoid process of the shoulder blade (scapula). By performing this action, the subscapular fascia, and subscapularis muscles (and subcoracoid bursae) reduce friction on the humeral head, which helps provide shoulder stability. (13)



PHYSIOLOGICAL CHANGES WITH FROZEN SHOULDER

Current literature supports the following physiological changes taking place during the process of developing Frozen Shoulder (2). During this process:

  • The capsule surrounding the shoulder joint becomes inflamed, thickened, and extremely rigid.

  • This inflammation is often accompanied by a decrease in synovial fluid levels within the capsule, followed by contraction of the joint capsule.

  • This combination of inflammation and contraction leaves less space for the humerus (upper arm bone) to move around.

Patients suffering from Frozen Shoulder usually have trouble with two ranges of motion - most commonly with shoulder abduction and external rotation.



The Three Phases of Frozen Shoulder

Current literature shows that the development of Frozen Shoulder is typically divided into three phases (2), with each phase lasting for several months before the change is noticed:

  1. Painful or Freezing Phase (2-9 months): This phase is characterized by pain with any movement and is accompanied by a decrease in the patient’s range of motion.

  2. Adhesion Phase (4-12 months): The pain level decreases and is accompanied by a substantial decrease in the shoulder’s range of motion. Range-of-motion declines during this stage due to the joint capsule thickening with excessive collagen. All the activities of daily living become extremely difficult to perform.

  3. Thawing or Resolution Phase (5-26 months): The range of motion will begin to increase, and the patient’s pain will diminish.

Note: Though these are the classical phases of Frozen Shoulder, it is my clinical experience that these phases can be greatly reduced in duration and intensity with the right program of therapy, exercise, and possible medication/injections (depending on the case).





EXAMINATION OF FROZEN SHOULDER

To effectively evaluate a patient who seems to be presenting with Frozen Shoulder you should:

  • Check active and passive ranges of motion in the shoulder, cervical spine, and thoracic region.

  • Check rib mobility, especially the first rib.

  • Check External Rotation of the shoulder: Test bilaterally, a positive test is when the affected side has 50% or greater loss of rotation when compared to the good side, or where there are less than 30 degrees of external rotation.

  • Verify if at least two other ROM planes are reduced by at least 25% when compared to the other side. For example, test the shoulder in abduction and then in flexion.

  • Check for active muscle guarding. Use the Coracoid Pain Test to evaluate. (The Coracoid Pain test uses digital pressure on the area of the coracoid process to determine if there is localized pain.


Frozen Shoulder Testing


This video covers some of the common orthopaedic examination procedures we use in examining a patient with Frozen Shoulder.




Shoulder Examination - Orthopaedic Testing


This video uses orthopaedic examination procedures to evaluate common causes of shoulder pain (including frozen shoulder) and how to diagnose them.


Upper Limb Neuro Exam

The upper limb neurological examination is part of the overall neurological examination process and is used to assess the motor and sensory neurons which supply the upper limbs. This assessment helps to detect any impairment of the nervous system. (Note: This video will be available for the public on October 7th, 2022)


Peripheral Vascular Examination - Key Points


A peripheral vascular examination is a valuable tool used for ruling out signs of vascular-related pathology. The detection and subsequent treatment of PVD can potentially mitigate cardiovascular and cerebrovascular complications. In this video we go over some of the common procedures we perform in daily clinical practice. This video is available for the public on November 14/2022.


Checking the Shoulder Joints


In addition to the standard orthopaedic and neurological testing we also check the mobility of all four shoulder joints:

  • Sternoclavicular (SC) Joint - Check elevation 45°, depression 5°, protraction 15°, retraction 15°, and axial rotation. A fused SC joint limits all shoulder motions.

  • Scapulothoracic Joint (ST) - Check for motion between the scapulae and the rib cage. The scapulae must be able to elevate, depress, protract, and retract over the rib cage. There must also be upward and downward rotation in the glenoid fossa.

  • Acromioclavicular (AC) Joint - The acromioclavicular joint allows a degree of axial rotation and anteroposterior movement. There is normally a 20-30° of total glide and rotation with other accompanying shoulder joint motions.

  • Glenohumeral (GH) Joint - In cases of Frozen Shoulder the Glenohumeral joint will be most limited in the Anterior and inferior capsular region. (8) The Glenohumeral joint should not be limited in all three planes of motion.

Clinical Tip: No muscles attach directly to the SC joint. The SC joint motion somewhat mimics the reciprocal motions of the Scapulae. The muscles that attach to the clavicle, which may affect clavicular motion, are the SCM, deltoid, pectoralis major (clavicular head), subclavius and trapezius.


RECOMMENDED ORTHOPAEDIC REFERENCE BOOKS

Orthopaedic Physical Assessment – David J. Magee https://amzn.to/3zgu0za

Dutton's Orthopaedic: Examination, Evaluation and Intervention, Fifth Edition https://amzn.to/3st1AOv



DIAGNOSTIC IMAGING FOR FROZEN SHOULDER

Your practitioner may order X-rays, primarily to rule out associated or pathological conditions.

It is my recommendation that all patients presenting with Frozen Shoulder should undergo plain radiography imaging. This could help rule out infections, metastatic process, large areas of calcification, avascular necrosis of the humeral head, or charcot joints.

Note: Patients who smoke (or have a history of smoking) should also have a chest X-Ray with apical views. This is to rule out a Pancoast Tumor which can irritate the brachial plexus, making this a possible cause of Frozen Shoulder type symptoms (14).




DIFFERENTIAL DIAGNOSIS FOR FROZEN SHOULDER

Practitioners should be aware that there are several conditions that could present with similar symptoms to Frozen Shoulder. It is important to consider these conditions in your differential diagnosis. (5) These other conditions include:

  • Bursitis: Patients with bursitis will show an increased passive range of motion (PROM) as compared with Frozen Shoulder. Both syndromes will be very painful during the initial stages.

  • Osteoarthritis: As with Frozen Shoulder, abduction and external rotation will be limited in active range of motion (AROM). The difference is that PROM will not be limited to osteoarthritis.

  • Rotator Cuff Syndrome: Symptoms can be very similar to Frozen Shoulder. MRI or ultrasound may be required to differentiate between these two syndromes.




FROZEN SHOULDER TREATMENT


Manual therapy and exercise should be the first line of treatment for all stages of Frozen shoulder (19). (There is considerable research to support the use of manual therapy in the treatment of Frozen Shoulder (2).)

The objective of manual therapy is to reduce pain, increase mobility, and provide functional improvements with activities of daily living (ADL). The exact combination of treatment and exercise recommendations that we typically provide does vary based on the current phase of the Frozen Shoulder.


Below are examples of manual therapy approaches that we could use depending on the specific needs of each patient. Note: These videos are for demonstration purposes only, MSR procedures should only be performed by a qualified practitioner.


5 Point Shoulder Joint Mobilization - Part 1: In this video I demonstrate the Motion Specific Release "5 Point Shoulder Joint Mobilization" protocol. When we think of the shoulder, we often think of it as being just one joint. In reality, we must consider five different joints. Understanding the inter‐relationships between the structures in these five joints will play a critical role in successfully resolving shoulder injuries.


5 Point Shoulder Joint Mobilization - Part 2:

Dr. Abelson demonstrates some very effective MSR procedures for shoulder joint mobilization.







6 ‐ Point MSR Rotator Cuff Protocol: The rotator cuff is made up of four major muscles and their associated tendons: supraspinatus, infraspinatus, teres minor, and the subscapularis. This group of muscles is also referred to as the SITS muscles (the first letter of their names). The SITS muscles are involved in almost every type of shoulder movement. It is extremely important to have strong, flexible, and balanced SITS muscles in order to maintain optimal shoulder function.





CONCURRENT TREATMENT


Frozen Shoulder is a condition that I often treat concurrently with a medical practitioner. Manual Therapy, with exercise, and in combination with anti-inflammatory medications and glenohumeral joint injections can often help break the pain cycle much faster.

You may be wondering, "Why don't I just get the injections - without the therapy or exercise?" Unfortunately, injections by themselves are not as effective as when they are combined with manual therapy and exercise. Research has shown that when manual therapy and intra-articular injections are combined, patients improve their function and achieve increased ranges-of-motion much more rapidly than with injections alone (15,16).

Note: anti-inflammatory medications have been found to be most helpful to patients during Phase 1 of Frozen Shoulder. The medication allows the patient to better tolerate therapy and exercise. Unfortunately, in cases with prolonged symptoms, anti-inflammatory medications have NOT been shown to decrease pain or improve function (19).




TREATMENT DURING PAINFUL OR FREEZING PHASE

Once a practitioner has completed his/her analysis, and determined which phase of Frozen Shoulder that the patient is suffering from, then an appropriate treatment and exercises plan can be implemented.

During Phase 1 – Painful or Freezing Phase, we recommend using the following treatment strategy.

  • Avoid all painful activities.

  • Use Heat. Heating the involved shoulder to treatment to increase blood circulation, increase range of motion, and reduce muscle viscosity. Heat causes a neuromuscular mediated relaxation response. (6)

  • Perform all exercises in a pain-free AROM (Active Range of Motion).

  • Perform stretching exercises for just a short duration (2 to 5 seconds), but they should be performed 4 to 6 times per day.

  • Perform pulley or pole exercises, depending on patient tolerance.

  • Pendulum exercises can be performed several times per day.

  • Apply gentle manual therapy procedures to patient tolerance. These procedures include both osseous and soft tissue techniques. The objective of these procedures is to increase range of motion, reduce muscle viscosity, increase blood flow, displace waste produces, and speed healing.

  • Mobilize/manipulate restrictions in the thoracic cervical region if indicated.

Note: It is extremely important that you DO NOT try to force an increase in range of motion. Also as mentioned we recommend concurrent treatment combining therapy, exercise and injections or medication.




TREATMENT DURING THE ADHESION PHASE

As we discussed earlier, the Adhesion Phase typically occurs after four months. During this phase, we recommend that you:


  • Use heat to increase range-of-motion, and reduce muscle viscosity.

  • Stretching exercises can become more aggressive to increase AROM (perform within patient tolerance which should be increasing).

  • Apply prolonged stretches, with a minimal load, to increase plastic elongation. (3) We suggest using light hand weights to increase stretching effectiveness.

  • Mobilize the shoulder joint to end-range to improve joint motion and stretch contracted peri-articular structures (muscles, ligaments and tendons). These techniques include shoulder joint distraction procedures.

  • Perform phase one manual therapy procedures within patient tolerance. Slightly increase the intensity and begin to consider a larger kinetic chain.



TREATMENT DURING THAWING OR RESOLUTION PHASE

Treatments for Thawing or Resolution Phase

As the patient's condition improves, we encourage them to:


  • Use heat to increase range-of-motion, and reduce muscle viscosity.

  • Increase the frequency and duration of the stretching routine, to patient tolerance.

  • Apply pulley or pole exercises to patient tolerance, several times per day. (See Video)

  • Use manual therapy procedures to patient tolerance. Consider both local and global tensegrity. Procedures must include both osseous and soft tissue protocols.

THE EARLIER THE BETTER

Manual Therapy is Supported by Research

Research supports the use of manual therapy to improve patient function during any stage of Frozen Shoulder. The research also shows that the greatest improvements are seen when the treatment is administered at an early stage (17,18).



FROZEN SHOULDER EXERCISES



Frozen Shoulder Routine - Motion Specific Release: We have found the following exercises to be an important component of the over all strategy in treating Frozen Shoulder. This is a sample of some of the exercises that we prescribe to our patients.





5 Daily Shoulder Mobilization Exercises: As patients progress, we will start to introduce other exercises into the program such as these shoulder mobilization exercises.




Strengthening Internal & External Shoulder Rotation: Once your range of motion improves, you can add in rotator cuff strengthening exercises to your routine. Before performing strengthening exercises warm up your shoulder, and do your stretching exercises before you perform strengthening exercises.


EQUIPMENT

Theraband/Resistance bands at Amazon: https://amzn.to/3VWQheW





WHEN CONSERVATIVE CARE IS NOT ENOUGH

Surgical Options

If conservative care does not achieve the desired results, then surgery may be an option you want to consider.

Today there are several surgical options that your doctor may want you to consider.

  • A selective arthroscopic capsular release is sometimes recommended for patients with Frozen Shoulder (20).

  • Also, research has shown that a procedure called an inferior capsulotomy has yielded good results in certain cases (21).

Whether or not one of these procedures is right for you is something you need to discuss with your medical doctor.

  • Most practitioners will not recommend these procedures unless symptoms persist after sufficient conservative treatment has been implemented for at least six months.

  • The benefits and possible complications of surgery are something that needs to be carefully discussed with your medical practitioner.




CONCLUSION

Every case of Frozen Shoulder is different and must be treated on an individual basis.

The good news is that most cases of Frozen Shoulder respond well to manual therapy in combination with an appropriate exercise program. In some cases, using medications and injections could speed the process when combined with conservative care.

In our experience, combining therapies can effectively reduce pain, increase range of motion, and get patients back to their active lifestyle in a much shorter period.





DR. BRIAN ABELSON DC.

Dr. Abelson believes in running an Evidence-Based Practice (EBP). EBPs strive to adhere to the best research evidence available while combining their clinical expertise with the specific values of each patient.

Dr. Abelson is the developer of Motion Specific Release (MSR) Treatment Systems. His clinical practice is located in Calgary, Alberta (Kinetic Health). He has recently authored his 10th publication, which will be available later this year.




Make Your Appointment Today!

Please make an appointment with our incredible team at Kinetic Health in NW Calgary, Alberta. Call Kinetic Health at 403-241-3772 to make an appointment today, or click the MSR logo to the right. We look forward to seeing you!






Discover more helpful information about shoulder and upper body injuries in my book “Exercises for the Shoulder to Hand.”

This book guides you through the exercises you need to rehabilitate your shoulder, elbow, wrist, and hand injuries.

These exercises help you progress logically through Beginner, Intermediate, and Advanced routines and aid in effectively building flexibility, strength and power throughout the upper body!





REFERENCES

  1. Brue S et al. Idiopathic adhesive capsulitis of the shoulder: a review. Knee Surg Sports Traumatol Arthrosc. 2007. 15:1048-1054.

  2. Cleland J, Durall CJ. Physical therapy for adhesive capsulitis: Systematic review. Physiotherapy 2002;88:450-457.

  3. Dias R, Cutts S, Massoud S. Frozen shoulder. BMJ 2005; 331:1453-6.

  4. Green S, Buchbinder R, Hetrick S. Physiotherapy interventions for shoulder pain. Cochrane Database systematic Review The Cochrane library. 2006;3.

  5. Hollmann L, Halaki M, Haber M, Herbert R, Dalton S, Ginn K. Determining the contribution of active stiffness to reduced range of motion in frozen shoulder. Physiotherapy 2015;101:e585.

  6. Kelley M, Mcclure P, Leggin B. Frozen shoulder: Evidence and a proposed model guiding rehabilitation. J Orthop Sports Phys Ther 2009;39:135-148.

  7. Littlewood C, May S, Walters S. A review of systematic reviews of the effectiveness of conservative interventions for rotator cuff tendinopathy. Shoulder & Elbow. 2013 Jul 1;5(3):151-67.

  8. Mitsh J, Casey J, McKinnis R, Kegerreis S, Stikeleather J. Investigation of a consistent pattern of motion restriction in patients with adhesive capsulitis. J Man Manip Ther 2004;12:153-159.

  9. Neviaser AS, Hannafin JA. Adhesive Capsulitis: A Review of Current Treatment. The Am J Sports Med 2010;38:2346-56.

  10. Vermeulen HM, Rozing PM, Obermann WR, Cessie S, Vlieland T. Comparison of high-grade and low-grade mobilization techniques in the management of adhesive capsulitis of the shoulder: Randomized clinical trial. Phys Ther 2006;86:355-368.

  11. Walmsley S, Rivett DA, Osmotherly PG. Adhesive capsulitis: Establishing consensus on clinical identifiers for stage 1 using the delphi technique. Phys Ther 2009;89:906-917.

  12. Smoking Predisposes to Rotator Cuff Pathology and Shoulder Dysfunction: A Systematic Review Arthroscopy. 2015 Aug;31(8):1598-605. doi: 10.1016/j.arthro.2015.01.026. Epub 2015 Mar 19.

  13. Stecco, Carla; Stecco, Carla. Functional Atlas of the Human Fascial System E-Book (Page 241)

  14. Sano H, Hatori M, Mineta M, et al. Tumors masked as frozen shoulders: A retrospective analysis. J Shoulder Elbow Surg. 2009 Jun 30. [Medline].

  15. Carette S, Moffet H, Tardif J, et al. Intraarticular corticosteroids, supervised physiotherapy, or a combination of the two in the treatment of adhesive capsulitis of the shoulder: a placebo-controlled trial. Arthritis Rheum. 2003 Mar. 48(3):829-38.

  16. Ulusoy H, Sarica N, Arslan S, Olcay C, Erkorkmaz U. The efficacy of supervised physiotherapy for the treatment of adhesive capsulitis. Bratisl Lek Listy. 2011. 112(4):204-7. [Medline].

  17. Vermeulen HM, Obermann WR, Burger BJ, et al. End-range mobilization techniques in adhesive capsulitis of the shoulder joint: A multiple-subject case report. Phys Ther. 2000 Dec. 80(12):1204-13.

  18. Liaw SC. The effect and timing of physiotherapy on change in range of motion and function in frozen shoulder. Physiother Singapore. Sep 2000. 3(3):82-6.

  19. Hsu JE, Anakwenze OA, Warrender WJ, Abboud JA. Current review of adhesive capsulitis. J Shoulder Elbow Surg. 2011 Apr. 20(3):502-14. [Medline].

  20. Chen J, Chen S, Li Y, Hua Y, Li H. Is the extended release of the inferior glenohumeral ligament necessary for frozen shoulder?. Arthroscopy. 2010 Apr. 26(4):529-35. [Medline].

  21. Miyazaki AN, Santos PD, Silva LA, Sella GD, Carrenho L, Checchia SL. Clinical evaluation of arthroscopic treatment of shoulder adhesive capsulitis. Rev Bras Ortop. 2016 Dec 20. 52(1):61-68.
